Kobin LeafScan HR 512i
The Kobin LeafScan HR 512i combines SVC’s field-proven hyperspectral sensing technology with Kobin’s cloud-based analytics platform (LeafIQ) to deliver rapid, non-destructive leaf measurements directly in the field.
Kobin LeafScan HR-512i Specifications | |||
| Spectral Range | 350 nm – 1050 nm | ||
| Internal Memory | 1000 scans | ||
| Channels | 512 | ||
| Linear Array | (1) 512ch Si, 350 – 1050 nm | ||
| Spectral Resolution (FWHM) | 3.2 nm, 700 nm | ||
| Bandwidth (nominal) | 1.5 nm, 350 – 1050 nm | ||
| Minimum Integration | 10 millisecond | ||
| FOV | 25˚ standard/ 4˚, 8˚, 14˚ optional armored fiber optic | ||
| Noise Equivalent Radiance | ≤ 0.8 x 10-9 W/cm2/nm/sr @ 700 nm | ||
| Stand Alone Measurements (no computer required) | Standard | ||
| Calibration Accuracy (NIST Traceable) | ±5% @ 400 nm ±4% @ 700 nm | ||
| Wavelength Reproducibility | 0.1 nm | ||
| Dark Current Correction | Automatic | ||
| Spectrum Averaging | Automatic/selectable | ||
| Internal Digital Camera | Supplied | ||
| Internal GPS | Supplied | ||
Physical Specifications | |||
| Head Size | 8.75” x 6.5” x 3.0” | ||
| Weight | 5.2lbs., 2.4kg | ||
| Battery Type | 7.4 V lithium ion | ||
| Battery Life | 8 hours approximately | ||
AI-Powered Spectral Sensing for Precision Agriculture
Leaf spectra collected with the LeafScan HR 512i are securely transferred to the Kobin platform, where they can be used across multiple Kobin solutions, including Crop Monitor and Research Agents. In LeafIQ, spectral measurements are converted into AI-powered nutrient analysis, providing actionable insights to support precision crop management.
Learn more about Kobin solutions at www.kobin.com
Sample Scans
Features
· Portable field-ready hyperspectral sensing system
· Non-destructive leaf measurements
· Secure cloud-connected workflow
· AI-powered nutrient analysis through LeafIQ
· Integration with Kobin’s Crop Monitor and Research Agents
· Mobile and web access through the Kobin platform
Simple Workflow
- Collect leaf spectra with the LeafScan HR 512i
- Upload data to the Kobin cloud
- Analyze results using LeafIQ, Crop Monitor, or Research Agents
- Access insights from any supported device
Applications
- Nutrient monitoring
- Field scouting
- Agricultural research and field trials
- Precision stress management
Note: A Kobin account and active software subscription are required to access cloud-based analytics and AI services.
